RY320 -2 color three-station printing machine-Printing machine-Products-HENGHAO

Name:

RY320 -2 color three-station printing machine

Product description:

The reasonable and simple design structure, reliable quality, and affordable price of this 2-color flexographic printing machine guarantee its uniqueness. Can greatly save production time and cost. This machine is simple to operate, easy to use and other powerful functions, which is the most ideal for small and medium-sized enterprises, especially customers who have low printing requirements.

Features:

1. Use ceramic anilox roller to transfer ink.

2. Each printing unit adopts 360°circumferential registration adjustment.

3. The computer correction device is located in front of the printing group. This design keeps the roll paper in the correct left and right positions during the entire production process. (Optional)

4. Unwinding and rewinding are controlled by magnetic powder automatic tension, and double rewinding can be added.

5. The ink roller can be detached automatically when parking, and run at low speed to prevent ink from drying out.

6. The main motor adopts imported frequency conversion stepless speed regulation.

7. It is the ideal model for printing commercial bills and high-end stickers for all kinds of printing plants, which can be completed at one time from tube feeding, printing, automatic infrared drying, and rewinding.

Technical parameter
Printing speed:	50m-60m/min	Voltage:	380V±10%
Printing colors:	2 colors	Total power:	5kw
Feeding width:	320mm	Total air pressure:	0.6MP
Maximum unwinding diameter:	600mm	Lubrication system:	Artificial
Maximum winding diameter:	600mm	weight:	500kg
Maximum printing size:	175-370mm	Dimensions:	1200mmX1200mmX1400mm
Overprint accuracy:	±0.15mm

The above technical parameters and pictures are for reference only, the actual product shall prevail
